Szczegóły produktu
Miejsce pochodzenia: Hangzhou, Chiny
Nazwa handlowa: Zoyo
Orzecznictwo: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Numer modelu: ZY009601
Warunki płatności i wysyłki
Minimalne zamówienie: Elastyczne minimalne zamówienie
Cena: $2~$500 per piece
Szczegóły pakowania: Zindywidualizowane
Czas dostawy: 3-4 tygodnie
Zasady płatności: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Możliwość Supply: 5-20 tys sztuk dziennie
Rozmiar (cale): |
0,96 |
Rozstrzygnięcie: |
128*64 |
Obszar aktywny ((mm): |
19,26*1,41 |
Temperatura pracy: |
-20℃～70℃ |
Rozmiar (cale): |
0,96 |
Rozstrzygnięcie: |
128*64 |
Obszar aktywny ((mm): |
19,26*1,41 |
Temperatura pracy: |
-20℃～70℃ |
| GENERAL SPECIFICATIONS | ||||
| Item | Specification | Unit | Note | |
| Screen Size | 0.96 | |||
| Resolution | 128*64 | pixels | ||
| Operating Temperature | ‐20℃~70℃ | |||
| Storage Temperature | ‐30℃~80℃ | |||
| Module Size | Horizontal (H) | 26.7 | mm | typ |
| Vertical (V) | 19.26 | |||
| Thickness (T) | 1.41 | |||
| Active Area | Horizontal | 21.744 | mm | |
| Vertical | 10.864 | |||
| Interface Type | MCU/4SPI | |||
| Application | Blood Glucose Meter | |||
The difference between PMOLED and AMOLED
| Feature | PMOLED | AMOLED |
| Matrix Type | Passive Matrix | Active Matrix |
| Control Mechanism | Sequential control of rows/columns | Individual pixel control via TFTs |
| Resolution | Lower | Higher |
| Brightness/Contrast | Good, but less uniform | Superior brightness and contrast |
| Refresh Rate | Lower, potential flickering | Higher, suitable for dynamic content |
| Power Consumption | Higher for larger/bright content | More efficient, especially with dark content |
| Complexity/Cost | Simpler, cheaper | More complex, more expensive |
| Typical Applications | Small, simple displays | High-end, high-resolution displays |
